主要特點包括：
- 封閉式硬化玻璃、快速回應顯示器，可實現最大的可見性和耐化學性
- 最先進的振動感測器檢測與允許閾值的偏差，並自動停止運作
- 清晰顯示所有重要信息
- 用於控制動力學敏感反應和提醒的整合定時器/計數器
- 黏度高達 10,000 mPas，體積高達 15 L
- 0/30 – 2,000 rpm 之間的連續可調速度
- USB 接口，例如用於使用 labworldsoft® 記錄參數或安裝韌體更新
- 直觀簡單的處理；觸控感應表面，使用壽命長
- 顯示器上的溫度讀數
- 耐化學外殼
- 按鍵鎖定功能
- 微處理器控制的調速器在即使黏度發生變化的情況下也能保持恆定的轉速
| Stirring quantity max. per stirring position (H2O) | 15 l |
| Motor rating input | 60 W |
| Motor rating output | 46 W |
| Motor principle | Brushless DC |
| Speed display | LCD |
| Speed min. | 50 rpm |
| Speed min. | 0/50 rpm |
| Speed max. | 2000 rpm |
| Viscosity max. | 10000 mPas |
| Output max. at stirring shaft | 42 W |
| Permissible ON time | 100 % |
| Torque max. at stirring shaft | 20 Ncm |
| Speed control | Turning knob |
| Setting accuracy speed | 1 ±rpm |
| Deviation of speed measurement n > 300rpm | 3 ±% |
| Stirring element fastening | chuck |
| Connection for ext. temperature sensor | PT1000 |
| Temperature display | yes |
| Chuck range diameter | 8.5 – 8 mm |
| Hollow shaft, inner diameter | 8.5 mm |
| Hollow shaft (push-through – when stopped) | yes |
| Fastening on stand | extension arm |
| Extension arm diameter | 13 mm |
| Extension arm length | 160 mm |
| Torque display | yes |
| Speed control | electronic |
| Nominal torque | 0.2 Nm |
| Torque measurement | trend |
| Deviation of torque measurement I | 3 ±Ncm |
| Timer | yes |
| Timer display | LCD |
| Time setting range | 0 – 6000 min |
| Temperature measuring range | -10 – 350 °C |
| Temperature measurement resolution | 0.1 K |
| Accuracy of temperature measurement | ±0.05 + tolerance PT1000 (DIN IEC 751 Class A) K |
| Limit deviation temperature sensor | ≤ ± (0.15 + 0.002xITI) K |
| Housing material | alu-cast coating / thermoplastic polymer |
| Communication distance (depend onbuilding) max. | 150 m |
| Dimensions (W x H x D) | 70 x 193 x 154 mm |
| Weight | 1.56 kg |
| Permissible ambient temperature | 5 – 40 °C |
| Permissible relative humidity | 80 % |
| Protection class according to DIN EN 60529 | IP 54 |
| USB interface | yes |
| Voltage | 100 – 240 V |
| Frequency | 50/60 Hz |
| Power input | 69 W |
| DC Voltage | 24 V= |
| Current consumption | 2900 mA |
Key features include:
- Hardened glass enclosed, fast response display for maximum visibility and chemical resistance
- State-of-art vibration sensors detect deviations from permissible thresholds and automatically stop the process
- Clear display for all essential information at a glance
- Integrated timer / counter for the control of kinetic sensitive reactions and reminders
- Viscosities up to 10,000 mPas and volumes of up to 15 l
- Continuously adjustable speed between 0/30 – 2,000 rpm
- USB interface, e.g. for documenting parameters using labworldsoft® or installing firmware updates
- Intuitive and simple handling; touch-sensitive surface for long service life
- Temperature reading on display
- Chemical resistant housing
- Key lock function
- Microprocessor-controlled speed governor for constant rotational speed, even with changes in viscosity
| Stirring quantity max. per stirring position (H2O) | 15 l |
| Motor rating input | 60 W |
| Motor rating output | 46 W |
| Motor principle | Brushless DC |
| Speed display | LCD |
| Speed min. | 50 rpm |
| Speed min. | 0/50 rpm |
| Speed max. | 2000 rpm |
| Viscosity max. | 10000 mPas |
| Output max. at stirring shaft | 42 W |
| Permissible ON time | 100 % |
| Torque max. at stirring shaft | 20 Ncm |
| Speed control | Turning knob |
| Setting accuracy speed | 1 ±rpm |
| Deviation of speed measurement n > 300rpm | 3 ±% |
| Stirring element fastening | chuck |
| Connection for ext. temperature sensor | PT1000 |
| Temperature display | yes |
| Chuck range diameter | 8.5 – 8 mm |
| Hollow shaft, inner diameter | 8.5 mm |
| Hollow shaft (push-through – when stopped) | yes |
| Fastening on stand | extension arm |
| Extension arm diameter | 13 mm |
| Extension arm length | 160 mm |
| Torque display | yes |
| Speed control | electronic |
| Nominal torque | 0.2 Nm |
| Torque measurement | trend |
| Deviation of torque measurement I | 3 ±Ncm |
| Timer | yes |
| Timer display | LCD |
| Time setting range | 0 – 6000 min |
| Temperature measuring range | -10 – 350 °C |
| Temperature measurement resolution | 0.1 K |
| Accuracy of temperature measurement | ±0.05 + tolerance PT1000 (DIN IEC 751 Class A) K |
| Limit deviation temperature sensor | ≤ ± (0.15 + 0.002xITI) K |
| Housing material | alu-cast coating / thermoplastic polymer |
| Communication distance (depend onbuilding) max. | 150 m |
| Dimensions (W x H x D) | 70 x 193 x 154 mm |
| Weight | 1.56 kg |
| Permissible ambient temperature | 5 – 40 °C |
| Permissible relative humidity | 80 % |
| Protection class according to DIN EN 60529 | IP 54 |
| USB interface | yes |
| Voltage | 100 – 240 V |
| Frequency | 50/60 Hz |
| Power input | 69 W |
| DC Voltage | 24 V= |
| Current consumption | 2900 mA |
